Commercial Windows
Elton’s injection molded frames deliver the best in quality and appearance for your commercial door. The unique, screw-together design makes installation simple – and our polypropylene frames will not discolor! Please see the chart below for specifications, colors, glass options and door thicknesses.
0120
Screw-Together Window
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 0120 | 12 15/16” Outside Diameter | 11 15/16” Diameter | 10 3/16” Inside Diameter |
| 328mm Outside Diameter | 303mm Diameter | 274mm Inside Diameter |
| Frame Colour | Glass Options | Available Door Thicknesses / Box | |||||||
|---|---|---|---|---|---|---|---|---|---|
| 1 1/2” | 1 5/8” | 2” | FO | ||||||
| Black, White | Sealed Plexi, Sealed Lexan | 16 | 16 | 12 | 16 | ||||
0624
Screw-Together Window
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 0624 | 23 13/16” x 5 11/16” | 22 15/16” x 4 7/8” | 21 1/4” x 3 1/4” |
| 605mm x 144mm | 583mm x 124mm | 541mm x 82mm |
| Frame Colour | Glass Options | Available Door Thicknesses / Box | ||||||
|---|---|---|---|---|---|---|---|---|
| PAN | 1 3/8” | 1 1/2” | 1 5/8” | 1 3/4” | 2” | FO | ||
| Black, White, Cream, Sandstone, Brown, Grey |
See chart for glass options | 24 | 18 | 16 | 16 | 16 | 14 | 18 |
0824
Screw-Together Window.
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 0824 | 23 15/16” x 7 15/16” | 23 1/8” x 7 1/8” | 21 9/16” x 5 1/5” |
| 608mm x 202mm | 583mm x 181mm | 547mm x 140mm |
| Frame Colour | Glass Options | Available Door Thicknesses / Box | |||||||
|---|---|---|---|---|---|---|---|---|---|
| PAN | 1 3/8” | 1 1/2” | 1 5/8” | 1 3/4” | 2” | 3” | FO | ||
| Black, White, Cream, Sandstone, Brown, Grey | See chart for glass options | N/A | 14 | 14 | 12 | 12 | 10 | 14 | 14 |
1224
For flush doors.
Screw-Together Window.
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 1224 | 25 1/8” x 13 1/8” | 24 1/16” x 12” | 21 11/16” x 9 5/8” |
| 638mm x 334mm | 611mm x 305mm | 551mm x 245mm |
| Frame Colour | Glass Options | Available Door Thicknesses / Box | |||||||
|---|---|---|---|---|---|---|---|---|---|
| PAN | 1 3/8” | 1 1/2” | 1 5/8” | 1 3/4” | 2” | 3” | FO | ||
| Black, White, Cream, Sandstone, Brown, Grey | See chart for glass options | N/A | 8 | 8 | 6 | 6 | 6 | 8 | 8 |
1225
For ribbed doors.
Screw-Together Window
Frames For Deep Ribbed Pan Door
1225 will fit most door manufacturers’ ribbed panels. The tabs on our 1225 frame fit right into the deep ribs of the door. This saves installation time, as there’s no need to fill the ribs with caulking. The interior frame for a pan door is designed to go right over the deep ribs perfectly, lining up the screw holes with the exterior frame. You can mix and match 1224 & 1225 to fit ribbed or flush sections for pan or insulated doors.
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 1225 | 25 1/8” x 13 1/8” | 23 7/8” x 11 13/16” | 21 11/16” x 9 5/8” |
| 638mm x 334mm | 606mm x 300mm | 552mm x 246mm |
| Frame Colour | Glass Options | Available Door Thicknesses / Box | |||||||
|---|---|---|---|---|---|---|---|---|---|
| PAN | 1 3/8” | 1 1/2” | 1 5/8” | 1 3/4” | 2” | 3” | FO | ||
| Black, White, Cream, Sandstone, Brown, Grey | See chart for glass options | 15 | 8 | 8 | 6 | 6 | 6 | 6 | 10 |
1326
Screw-Together Window
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 1326 | 26 1/8” x 13 9/16” | 25 3/16” x 12 5/8” | 23 7/16” x 10 13/16” Corner Cut 4” Radius |
| 663mm x 344mm | 637mm x 319mm | 595mm x 275mm Corner Cut 101.60mm Radius | |
| *1326 Cut-out is oval. Please click here for a template. | |||
| Frame Colour | Glass Options | Available Door Thicknesses / Box | |||||||
|---|---|---|---|---|---|---|---|---|---|
| PAN | 1” | 1 3/8” | 1 1/2” | 1 5/8” | 1 3/4” | 2” | FO | ||
| Black, White | Sealed Plexi, Sealed Lexan | N/A | 8 | 8 | 8 | 8 | 6 | 6 | 8 |
1634
Screw-Together Window
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 1634 | 35 1/8” x 17 1/8” | 33 7/8” x 15 7/8” | 31 3/4” x 13 11/16” |
| 892mm x 435mm | 861mm x 403mm | 806mm x 348mm |
| Frame Colour | Glass Options | Available Door Thicknesses / Box | |||||||
|---|---|---|---|---|---|---|---|---|---|
| PAN | 1 3/8” | 1 1/2” | 1 5/8” | 1 3/4” | 2” | 3” | FO | ||
| Black, White, Cream, Sandstone, Brown, Grey | See chart for glass options | N/A | 4 | 4 | 4 | 4 | 4 | 6 | 6 |
1324
Screw-Together Window
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 1324 | 26 3/4”x 14 1/2” | 25 5/8” x 13 3/8” | 23 7/8” x 11 9/16” |
| 679mm x 369mm | 651mm x 340mm | 606mm x 294mm |
| Frame Colour | Glass Options | Available Door Thicknesses / Box | ||||||
|---|---|---|---|---|---|---|---|---|
| PAN | 1 3/8” | 1 1/2” | 1 5/8” | 1 3/4” | 2” | FO | ||
| Black | See chart for glass options | N/A | 8 | 8 | 6 | 6 | 6 | 8 |
1325
Clip-Together Window
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 1325 | 26 3/4”x 14 1/2” | 25 5/8” x 13 1/2” | 23 7/8” x 11 9/16” |
| 679mm x 369mm | 651mm x 340mm | 606mm x 294mm |
| Frame Colour | Glass Options | Available Door Thicknesses / Box | ||||||
|---|---|---|---|---|---|---|---|---|
| PAN | 1 3/8” | 1 1/2” | 1 5/8” | 1 3/4” | 2” | FO | ||
| Black | Sealed Plexi, Sealed Lexan | N/A | N/A | 8 | 8 | N/A | N/A | N/A |
1328
Clip-Together Window
| Model | Frame Size (tip-to-tip) | Cut-out Size | Vision Area |
|---|---|---|---|
| 1328 | 28 9/16” x 12 13/16” | 27 3/8” x 11 3/4” | 25 5/8” x 9 7/8” Corner Cut 2 3/4” Radius |
| 725mm x 325mm | 695mm x 298mm | 651mm x 251mm Corner Cut 69.85mm Radius |
| Frame Colour | Glass Options | Available Door Thicknesses / Box | ||||||
|---|---|---|---|---|---|---|---|---|
| PAN | 1 3/8” | 1 1/2” | 1 5/8” | 1 3/4” | 2” | FO | ||
| Black | Sealed Plexi, Sealed Lexan | N/A | N/A | 8 | 8 | N/A | N/A | N/A |
Glass Options
Most glass options can be ordered as single pane or insulated units
| Stock Glass | Special Glass |
|---|---|
|
|
